7281-6PG-300 Tech -specificaties
Conxall / Switchcraft - 7281-6PG-300 Technische specificaties, attributen, parameters en onderdelen met vergelijkbare specificaties als Conxall / Switchcraft - 7281-6PG-300
Productkenmerk | Attribuutwaarde | |
---|---|---|
Fabrikant | Conxall / Switchcraft | |
Nominale spanning | 600V | |
Beëindiging | Solder | |
afscherming | Unshielded | |
Shell Size, MIL | - | |
Shell Size - Insert | - | |
Shell Materiaal | Polyamide (PA), Nylon | |
Shell Afwerking | - | |
Serie | Mini-Con-X® | |
Packaging | Bulk | |
Andere namen | 7281-6PG-300-ND 72816PG300 SC2036 |
|
oriëntering | Keyed | |
Temperatuur | -40°C ~ 115°C | |
Aantal posities | 6 | |
montage Type | Panel Mount, Through Hole | |
montage Feature | Bulkhead - Front Side Nut | |
Vochtgevoeligheidsniveau (MSL) | 1 (Unlimited) |
Productkenmerk | Attribuutwaarde | |
---|---|---|
Materiaal Ontvlambaarheidsklasse | - | |
Fabrikant Standaard Levertijd | 10 Weeks | |
Loodvrije status / RoHS-status | Lead free / RoHS Compliant | |
Plaats het materiaal in | - | |
Ingress Protection | Weathertight | |
Kenmerken | - | |
bevestegingswijze | Bayonet Lock | |
gedetailleerde beschrijving | 6 Position Circular Connector Receptacle, Male Pins Solder Gold | |
Huidige score | 5.6A | |
Contact Material | Brass | |
Contact Voltooi Dikte - Paring | - | |
Contact Afronden - Paring | Gold | |
connector Type | Receptacle, Male Pins | |
Kleur | Black | |
Cable Opening | - | |
Backshell-materiaal, beplating | - | |
toepassingen | - |
De drie delen aan de rechterkant hebben vergelijkbare specificaties als Conxall / Switchcraft 7281-6PG-300.
Productkenmerk | ||||
---|---|---|---|---|
Onderdeel nummer | 7281-6PG-300 | 97-3106A-12S-3S(946) | MS3476L20-41P | 21033212518 |
Fabrikant | Conxall / Switchcraft | Amphenol Industrial Operations | Conesys | HARTING |
Andere namen | 7281-6PG-300-ND 72816PG300 SC2036 |
- | - | - |
Serie | Mini-Con-X® | 97 | Military, MIL-DTL-26482 Series II | har-flex® |
Cable Opening | - | - | - | - |
Nominale spanning | 600V | - | - | 60V |
afscherming | Unshielded | Unshielded | - | Shielded |
Shell Size - Insert | - | 12S-3 | 20-41 | M12-5 |
Backshell-materiaal, beplating | - | Aluminum Alloy, Black Zinc Alloy | - | - |
Vochtgevoeligheidsniveau (MSL) | 1 (Unlimited) | - | - | - |
Temperatuur | -40°C ~ 115°C | -55°C ~ 125°C | -55°C ~ 200°C | -40°C ~ 85°C |
toepassingen | - | Automotive, Industrial | - | - |
Aantal posities | 6 | 2 | 41 | 5 |
Shell Size, MIL | - | - | - | - |
Plaats het materiaal in | - | Diallyl Phthalate (DAP) | - | Liquid Crystal Polymer (LCP) |
bevestegingswijze | Bayonet Lock | Threaded | Bayonet Lock | - |
Contact Material | Brass | Copper Alloy | - | Copper Alloy |
Contact Voltooi Dikte - Paring | - | - | 50.0µin (1.27µm) | - |
Shell Materiaal | Polyamide (PA), Nylon | Aluminum Alloy | Aluminum Alloy | - |
Loodvrije status / RoHS-status | Lead free / RoHS Compliant | - | - | - |
oriëntering | Keyed | N (Normal) | N (Normal) | A |
connector Type | Receptacle, Male Pins | Plug, Female Sockets | Plug, Male Pins | Insert, Female Sockets |
Beëindiging | Solder | Solder Cup | Crimp | Solder |
Shell Afwerking | - | Black Zinc Alloy | Electroless Nickel | - |
Materiaal Ontvlambaarheidsklasse | - | - | - | - |
Contact Afronden - Paring | Gold | Silver | Gold | Gold |
Packaging | Bulk | - | - | - |
Kleur | Black | Black | - | - |
gedetailleerde beschrijving | 6 Position Circular Connector Receptacle, Male Pins Solder Gold | - | - | - |
montage Feature | Bulkhead - Front Side Nut | - | - | - |
Fabrikant Standaard Levertijd | 10 Weeks | - | - | - |
Kenmerken | - | Backshell, Coupling Nut | - | Board Guide, Insert Only, Requires Shell |
Ingress Protection | Weathertight | - | - | - |
Huidige score | 5.6A | - | - | - |
montage Type | Panel Mount, Through Hole | Free Hanging (In-Line) | Free Hanging (In-Line) | Through Hole |
Download 7281-6PG-300 PDF -datasheets en Conxall / Switchcraft -documentatie voor 7281-6PG-300 - Conxall / Switchcraft.
